技嘉GA-X99-Gaming 7 WIFI支持新一代Intel® Core™ i7 極致版處理器，使用業界領先的IR電源供應模塊控制器搭配PowIRstage™ 芯片。以下文檔是技嘉GA-X99-Gaming 7 WIFI使用手冊，為英文版本，有需要的朋友可立即下載此文檔。
溫馨提示：
本文檔為PDF格式文檔，因此需確保在閱讀之前你已經安裝了pdf閱讀器，如果尚未安裝閱讀器，建議下載福昕pdf閱讀器或其他PDF閱讀器，進行安裝后閱讀。
技嘉GA-X99-Gaming 7 WIFI使用手冊目錄
Box Contents...................................................................................................................6
Optional Items .................................................................................................................6
GA-X99-Gaming 7 WIFI Motherboard Layout ................................................................7
GA-X99-Gaming 7 WIFI Motherboard Block Diagram....................................................8
Chapter 1 Hardware Installation .....................................................................................9
1-1 Installation Precautions ................................................................................... 9
1-2 Product Specifications................................................................................... 10
1-3 Installing the CPU and CPU Cooler............................................................... 13
1-3-1 Installing the CPU ..................................................................................................13
1-3-2 Installing the CPU Cooler ......................................................................................15
1-4 Installing the Memory .................................................................................... 16
1-4-1 4 Channel Memory Configuration..........................................................................16
1-4-2 Installing a Memory................................................................................................17
1-5 Installing an Expansion Card......................................................................... 18
1-6 Setting up AMD CrossFire™/NVIDIA®
SLI™ Configuration............................. 19
1-7 Back Panel Connectors ................................................................................. 21
1-8 Installing the I/O Shield.................................................................................. 23
1-9 Onboard Buttons, Switches, and LEDs......................................................... 24
1-10 Changing the Operational Amplifier .............................................................. 26
1-11 Internal Connectors ....................................................................................... 27
Chapter 2 BIOS Setup ..................................................................................................39
2-1 Startup Screen............................................................................................... 40
2-2 The Main Menu.............................................................................................. 41
2-3 M.I.T. .............................................................................................................. 44
2-4 System Information........................................................................................ 56
2-5 BIOS Features ............................................................................................... 57
2-6 Peripherals..................................................................................................... 60
2-7 Chipset........................................................................................................... 62
2-8 Power Management....................................................................................... 65
2-9 Save & Exit .................................................................................................... 67
Chapter3 Configuring SATA Hard Drive(s) ..................................................................69
3-1 Configuring SATA Controllers........................................................................ 69
3-2 Installing the SATA RAID/AHCI Driver and Operating System..................... 81- 5 -
Chapter 4 Drivers Installation .......................................................................................85
4-1 Chipset Drivers .............................................................................................. 85
4-2 Application Software...................................................................................... 86
4-3 Information..................................................................................................... 86
Chapter 5 Unique Features...........................................................................................87
5-1 BIOS Update Utilities..................................................................................... 87
5-1-1 Updating the BIOS with the Q-Flash Utility...........................................................87
5-1-2 Updating the BIOS with the @BIOS Utility........................................................... 90
5-1-3 Using Q-Flash Plus................................................................................................91
5-2 APP Center.................................................................................................... 92
5-2-1 EasyTune................................................................................................................93
5-2-2 System Information Viewer................................................................................... 94
5-2-3 EZ Setup ............................................................................................................... 95
5-2-4 Fast Boot............................................................................................................... 98
5-2-5 Smart TimeLock.................................................................................................... 99
5-2-6 Smart Recovery 2 ............................................................................................... 100
5-2-7 USB Blocker.........................................................................................................102
5-2-8 Ambient LED........................................................................................................103
5-2-9 V-Tuner.................................................................................................................104
5-2-10 Smart Switch........................................................................................................105
5-2-11 Cloud Station Server........................................................................................... 106
5-2-12 Game Controller...................................................................................................112
Chapter 6 Appendix .................................................................................................... 113
6-1 Qualcomm® Atheros Killer Network Manager ..............................................113
6-2 Configuring Audio Input and Output.............................................................114
6-2-1 Configuring 2/5.1-Channel Audio ........................................................................114
6-2-2 Creative Software Suite.......................................................................................114
6-2-3 Configuring S/PDIF Out.......................................................................................118
6-2-4 Configuring Audio Recording ..............................................................................119
6-2-5 Using the Sound Recorder ..................................................................................121
6-3 Troubleshooting ........................................................................................... 122
6-3-1 Frequently Asked Questions ...............................................................................122
6-3-2 Troubleshooting Procedure .................................................................................123
6-4 Debug LED Codes....................................................................................... 125
Regulatory Statements ........................................................................................... 129
Contact Us .............................................................................................................. 135
技嘉GA-X99-Gaming 7 WIFI安裝cpu
技嘉GA-X99-Gaming 7 WIFI規格參數
中央處理器(CPU)
支持LGA2011-3插槽處理器：Intel® Core™ i7處理器
L3高速緩存取決于CPU
芯片組
Intel® X99 高速芯片組
內存
8個DDR4 DIMM插槽，最高支持到64 GB
* 由于Windows 32-bit操作系統的限制，若安裝超過4 GB容量內存時，實際上顯示之內存容量將少于實際安裝的內存容量。
支持4信道內存技術
支持DDR4 3000(O.C.) / 2800(O.C.) / 2666(O.C.) / 2400(O.C.) / 2133 MHz
支持non-ECC內存
支持Extreme Memory Profile (XMP)內存
支持RDIMM 1Rx8內存 (non-ECC模式運作)
音效
內建Creative® Sound Core 3D芯片
支持Sound Blaster Recon3Di
內建TI Burr Brown® OPA2134音效放大器芯片
支持High Definition Audio
支持2/5.1聲道
支持S/PDIF輸出
網絡
內建Qualcomm® Atheros Killer E2201網絡芯片(10/100/1000 Mbit)(LAN1)
內建Intel® GbE 網絡芯片(10/100/1000 Mbit) (LAN2)
