技嘉GA-X99-UD3支持新一代Intel® Core™ i7 極致版處理器，支持4插槽4 信道 DDR4內存架構，4-Way極致顯卡帶寬輸出配置。以下文檔是技嘉GA-X99-UD3使用手冊，為英文版本，有需要的朋友可立即下載此文檔。
溫馨提示：
本文檔為PDF格式文檔，因此需確保在閱讀之前你已經安裝了pdf閱讀器，如果尚未安裝閱讀器，建議下載福昕pdf閱讀器或其他PDF閱讀器，進行安裝后閱讀。
技嘉GA-X99-UD3使用手冊目錄
Box Contents ...................................................................................................................6
Optional Items .................................................................................................................6
GA-X99-UD3 Motherboard Layout ..................................................................................7
GA-X99-UD3 Motherboard Block Diagram ......................................................................8
Chapter 1 Hardware Installation .....................................................................................9
1-1Installation Precautions ....................................................................................9
1-2Product Specifications ....................................................................................10
1-3Installing the CPU and CPU Cooler ...............................................................13
1-3-1Installing the CPU ...................................................................................................13
1-3-2Installing the CPU Cooler .......................................................................................15
1-4Installing the Memory .....................................................................................16
1-4-14 Channel Memory Configuration ...........................................................................16
1-4-2Installing a Memory ................................................................................................17
1-5Installing an Expansion Card .........................................................................18
1-6Setting up AMD CrossFire ? /NVIDIA ? SLI ? Configuration ..............................19
1-7Back Panel Connectors ..................................................................................21
1-8Internal Connectors ........................................................................................23
Chapter 2 BIOS Setup ..................................................................................................37
2-1Startup Screen ...............................................................................................38
2-2The Main Menu ..............................................................................................39
2-3M.I.T. ..............................................................................................................42
2-4System Information ........................................................................................54
2-5BIOS Features ...............................................................................................55
2-6Peripherals .....................................................................................................58
2-7Chipset ...........................................................................................................59
2-8Power Management .......................................................................................62
2-9Save & Exit .....................................................................................................64
Chapter 3 Configuring SATA Hard Drive(s) ...................................................................65
3-1Configuring SATA Controllers .........................................................................65
3-2Installing the SATA RAID/AHCI Driver and Operating System .......................77
Chapter 4 Appendix ......................................................................................................81
Drivers Installation .....................................................................................................81
Regulatory Statements ..............................................................................................82
Contact Us ................................................................................................................87
技嘉GA-X99-UD3使用手冊——安裝cpu
技嘉GA-X99-UD3規格參數
中央處理器(CPU)
支持LGA2011-3插槽處理器：Intel® Core™ i7處理器
L3高速緩存取決于CPU
芯片組
Intel® X99 高速芯片組
內存
4個DDR4 DIMM插槽，最高支持到32 GB
*由于Windows 32-bit操作系統的限制，若安裝超過4 GB容量內存時，實際上顯示之內存容量將少于實際安裝的內存容量。
支持4信道內存技術
支持DDR4 3000(O.C.) / 2800(O.C.) / 2666(O.C.) / 2400(O.C.) / 2133 MHz
支持non-ECC內存
支持Extreme Memory Profile (XMP)內存
支持RDIMM 1Rx8內存 (non-ECC模式運作)
音效
內建Realtek® ALC1150芯片
支持High Definition Audio
支持2/4/5.1/7.1聲道
支持S/PDIF輸出
網絡
內建Intel® GbE 網絡芯片(10/100/1000 Mbit)
